Event Lighting PAR9X12OB - Outdoor Battery Parcan with Wireless DMX

The PAR9X12OB is a mid sized outdoor rated battery fixture, featuring 9x 12 W RGBWAU LEDs in a die cast aluminium housing, a 25° beam angle, WDMX on-board and IR control.

Photometrics

• Light Source: 9x 12 W RGBWAU LEDs
• Beam Angle: 25°
• LED Life: 50,000 hours

Effects

• Dimming: 0~100%

Power

• Input Voltages: 100V~240V AC,50/60Hz, 72 W
• Power Connection: Seetronic® Outdoor Tru1 in/out

Control

• Operational Modes: DMX, manual, auto, sound active, master/slave, Wireless DMX
• Display: LCD full colour control panel
• Control Protocol: DMX512, Wireless DMX (W-DMX)

• DMX Channels: 6 / 10
• DMX Interface: Seetronic® 5 Pin Outdoor DMX in/out

Housing

• Housing Materials: Die-cast aluminium, matte black finish
• IP Rating: IP65
• Cooling: Fanless Cooling

MISC

• Accessories Included: 1M Seetronic® Outdoor Powercon,  1M Seetronic® Outdoor DMX Cable
• Road case: PAR9X12OBC - charging case, fits 6 Units.

IMPORTANT:  Only use the provided Outdoor DMX cable in the device’s DMX out port. The use of other cables will cause the cable to become stuck in the port, requiring the unit to be repaired.
